Traxxas 92144-4 TRX-4 F-150 4WD Crawler Truck Blue Clipless Body
TRX-4® Ford® F-150® combines the unbeatable ground clearance and driving dynamics of Traxxas portal axles, sticky Canyon Trail™ tires, and a detailed clipless body. TRX-4 Ford F-150 is a leaner, performance-focused truck designed for increased climbing versatility. Sporting top-of-the-line Ranger XLT trim with chrome trim and chrome mag wheels, TRX-4 Ford F-150 elevates your off-road adventures with style.
TRX-4 Ford F-150 delivers scale looks with bright chrome bumpers, side trim, and side markers. The highly detailed two-tone grille, wipers, and door handles combine with clear windows to give the truck maximum scale authenticity.
Geared for raw torque, the single-speed transmission sheds valuable weight from the TRX-4's chassis for better weight distribution. Steel gears provide Traxxas-Tough durability and virtually maintenance-free operation.
Full-time locked front and rear axles transform the motor's torque into unstoppable climbing action. With no slippage possible, all four wheels claw with equal traction, powering TRX-4 F-150 over the toughest obstacles.
FEATURES:
- Officially Licensed 1979 Ford® F-150®Ranger XLT Body
- Scale details: grille, chrome bumpers, side mirrors, door handles, and wipers
- LED-ready headlights and tail lights
- Authentic decals
- Full Nylon composite wheel wells and floor pans
- Clipless Body mounting
- Clipless design for smooth body appearance
- Rugged internal body cage for added rigidity
- Body details mount directly to internal frame
- Trail-Tuned XL-5™ HV Waterproof Electronic Speed Control
- Fully waterproof design
- Five drive profiles
- Sport Mode — forward / brake / reverse
- Race Mode — forward / brake / no reverse
- Training Mode™ - 50% forward / 100% brake / 50% reverse (patented)
- Trail Mode — forward / brake / reverse / with trail-tuned drag brake in neutral
- Crawl Mode — forward / instant reverse - no neutral with 100% hill holding brake
- Traxxas EZ-Set® one-button setup
- Large, efficient heat sink
- Wide voltage latitude 6–7 cell NiMH (7.2–8.4 V) and 2–3s LiPo (7.4–11.1 V)
- Two stage low voltage protection (LVD)
- Titan® 550 Motor
- Powerful Titan 21T reverse rotation motor with internal cooling fan
- Precise preset gear mesh adjustments
- Motor retention separate from gear mesh
- TQ™ 2.4 GHz 2-Channel Radio
- Ergonomic transmitter with internal antenna
- Traxxas 6519 3-channel micro receiver with fail-safe security
- Patented o-ring sealed watertight receiver box keeps the receiver dry
- Extended Wheelbase Chassis
- Long 336 mm wheelbase for improved stability
- Full-length 1.5 mm thick steel frame rails
- Bumpers adjust fore and aft
- Rugged rock rails adjust for width
- Wire routing clips integrated into frame rails
- Innovative Battery Compartment
- Hinged battery strap allows quick and easy battery access
- No pins to lose
- Accommodates different height batteries
- Accepts full-size long battery packs
- Integrated compartment accepts smaller 1/16 scale batteries (with optional strap)
- Portal Axles
- Increase ground clearance
- Eliminate torque twist
- Steel gears
- Improve axle geometry and reduce strain on driveshafts
- Driveline
- Full-time shaft driven 4-wheel drive
- Tough 6 mm stub axles
- Steel front CV driveshafts
- Hardened steel rear axle shafts
- Spool-locked front and rear axles
- Steel gear transfer case
- Transmission
- Single-speed with steel gears
- Dual horizontal shafts
- Twin friction plate slipper clutch
- Easily removed for servicing
- Steering
- Chassis mounted 2075X metal gear digital servo
- Superior 45° steering angle
- Direct steering (no servo saver)
- Steering geometry corrected for bump steer
- Suspension
- Front — 3 link with panhard
- Rear — triangulated 4 link
- Heavy-duty rod ends with steel hollow balls
- 5 mm diameter steel link rods with 4 mm threaded ends
- Aluminum GTS Shocks
- Oil-filled coilover GTS shocks exclusive to TRX-4 chassis
- Silver-anodized aluminum bodies
- Threaded bodies with collars easily adjust ride height
- Silky smooth damping for the toughest trails
- O-ring cap seal and dual x-ring shaft seals
- Wheels and Tires
- 1.9″ chrome mag wheels wheels with hub inserts
- Pre-mounted 1.9" Canyon Trail tires with trail-tuned foam inserts
- Trail tuned S1 rubber compound
- 12 mm steel hex
- Sealed Ball Bearings
- Hex Hardware with Rust-Resistant Black Oxide Coating
- Requires Battery and Charger (Sold Separately)
SPECIFICATIONS:
- Type: Trail Truck / Crawler
- Skill Level: 1
- Chassis: Extended steel ladder frame
- Scale: 1/10
- Weight: 5.79 lb (2.63 kg)
- Length: 22.30 inches (566 mm)
- Width: 9.78 inches (249 mm)
- Height: 9.47 inches (241 mm)
- Track: 9.78 inches (249 mm)
- Wheelbase: 13.23 inches (336 mm)
- Center Ground Clearance: 3.14 inches (80 mm)
- Driveline: Shaft-driven 4WD
- Transmission: Single speed
- Differential Type: Spool (no differentials)
- Gear Pitch: 32 pitch
- Steering Servo: 2075X metal gear, digital high-torque waterproof
- Radio System: TQ™ 2.4 GHz 2-channel transmitter
- Battery Compartment Specs: 159 mm X 47 mm X 23 mm, 26 mm
INCLUDES:
- TRX-4 trail truck
- XL-5 HV waterproof electronic speed control
- Titan 21T reverse rotation motor
- TQ 2.4 GHz radio system
- High quality maintenance tools
Needed to complete:
- Batteries: TRX-4 accepts a wide variety of NiMH (6–7 cell) and LiPo (2s–3s) batteries
- Charger: The Traxxas EZ-Peak® charger 2970 is recommended for easy and fast charging performance
- AA Alkaline Batteries: Four AA alkaline batteries for the transmitter
