Traxxas 24054-61 XL-5 Brushed 2WD Bandit 1/10 RTR Off-Road Electric Buggy with LED Lights - Orange

The Traxxas Bandit® elevates RC buggy performance to a whole new level with faster speeds, innovative technology, hobby-grade durability, and a budget-friendly price. Bandit’s sleek, lightweight chassis delivers razor-sharp handling and blazing 35+ MPH* speed with blazing LED lights to guide the way. Pull the trigger and the Bandit rips massive rooster tails, soars over jumps, and lays down the power for excitement at every turn. Equally at home off-road or on pavement, Bandit’s fully waterproof electronics make even the wildest all-weather adventures possible. Step up to genuine Traxxas quality and performance and discover a whole new level of fun with the Traxxas Bandit.

Bandit now includes LED lighting as standard equipment for more fun after dark. Thick impact-resistant bumpers protect the lights against crash damage with fully-waterproof construction for all-weather fun.

The Bandit's powerful Titan 12T 550 motor is made for dirt-roosting torque, lightning-quick acceleration, big-air jumps, and just about any other 4-wheel fun that demands real horsepower. The Titan's oversize armature features 12 turns of pure copper wire for big torque and increased power-handling. The integrated cooling fan pulls cool air through the motor to keep temperatures down for more fun behind the wheel. The Titan 12T requires very little maintenance and provides consistent torque and high speeds run-after-run.

The waterproof XL-5 Electronic Speed Control handles the elements while smoothly supplying power to the motor. The XL-5 features three throttle profiles, low voltage detection, Thermal Shutdown Protection, 4-7 cell NiMH and 2-cell LiPo compatibility, and built-in BEC. High frequency operation combined with ultra-low resistance make the XL-5 an efficient and ultra-smooth fully proportional speed control. The exclusive and patented Training Mode™ reduces the overall power output of the XL-5 by 50%, making it easier for young or new drivers to develop their control skills before unleashing full-power.

FEATURES:

• 4-amp DC Peak Detecting Fast Charger
• Traxxas 3000mAh, 8.4V, 7-cell NiMH battery with iD®
• Waterproof electronics permit driving in water, mud, and snow
• High-torque Waterproof Traxxas 2056 steering servo
• Powerful Titan® 12T 550 motor with internal cooling fan
• Bandit reaches speeds in excess of 35 mph using the included
• optional 31-tooth pinion gear*
• High-performance waterproof XL-5™ Electronic Speed Control
• Innovative watersealed design
• Three drive profiles
• Sport Mode - forward / brake / reverse
• Race Mode - forward / brake
• Training Mode™ - 50% forward / brake / 50% reverse (patented)
• 12-turn motor limit for 550 size motors
• 15-turn motor limit for 540 size motors
• Traxxas EZ-Set® one-button setup
• LiPo and NiMH compatible with two-stage low-voltage detection
• Front and rear LED lighting
• Tough Magnum 272™ transmission
• Sealed gearbox protects the transmission
• Torque-Control™ slipper clutch system
• External gear cover with easy slipper clutch access
• Reliable planetary gear differential
• Telescoping U-joint driveshafts
• Fiber-composite monocoque chassis
• Easy access battery compartment
• Easy to remove and re-install wing mounting system
• Fully adjustable Ultra Shocks™ with X-ring technology
• White powder coated shock springs with responsive spring rate
• Durable solid camber links eliminate the need for adjustment
• Captured rod ends won't pop off for superior durability
• Alias® 2.2" step-pin rear tires and Alias ribbed front tires offer superior
• off-road traction
• Tires come pre-glued on black and chrome multi-spoke wheels
• ProGraphix® multi-colored painted bodies
• Bandit is backed by unparalleled Traxxas support and parts availability

SPECIFICATIONS:

• Length: 16.7 inches (423 mm)
• Front Track: 9.84 inches (250 mm)
• Rear Track: 9.84 inches (250 mm)
• Weight: 47.9 ounces (1.36 kg)
• Height (Overall): 7.01 inches (178 mm)
• Wheelbase: 11.25 inches (286 mm)
• Front Shock Length: Long
• Rear Shock Length: XX-Long
• Front Tires (Pre-Glued): Alias® Ribbed 2.2"
• Rear Tires (Pre-Glued): Alias® Step-Pin 2.2"
• Front Wheels: 2.2" black and chrome multi-spoke wheels
• Rear Wheels: 2.2" black and chrome multi-spoke wheels
• Electronic Speed Control: XL-5™ Electronic Speed Control
• Motor (Electric): Titan® 12T 550 (12-Turn 550)
• Steering Servo: #2056 High Torque Waterproof
• Transmitter: TQ 2.4GHz Radio
• Receiver: #6519 3-Channel Micro
• Gear Ratio (Internal): 2.72 (Final Drive: 10.17)
• Differential Type: Planetary
• Gear Pitch: 48-Pitch
• Transmission: Magnum 272™
• Steering: Dual bellcrank with servo saver
• Chassis Type: Molded tub
• Chassis Material: Composite Nylon
• Top-Speed: 35+mph*
• Skill Level: 1
• Battery Tray Dimensions: 166 mm x 47.5 mm x 28 mm
• Included Charger: 4-Amp DC Peak Detecting Fast Charger
• Included Batteries: Traxxas 3000mAh, 8.4V, 7-Cell NiMH Battery With iD®
• Required Batteries: 4 "AA" (Transmitter)

XL-5 (WATERPROOF) ESC SPECIFICATIONS:

• Input voltage: 4-7 Cells (4.8 to 8.4 Volts DC)
• Case Size: 31 mm x 55 mm x 15.5 mm
• Weight: 2.44 ounces
• Motor Limit: 15-turns** (540 Size)
• 12-turns** (550 Size)
• On Resistance Forward: 0.007 Ohms
• On Resistance Reverse: 0.014 Ohms
• BEC Voltage: 6.0 VDC
• BEC Current: 1A
• Power Wire: 14 Gauge / 5 inches
• Input Harness Wire: 26 Gauge / 9 inches
• PWM Frequency: 1600 Hz
• Low Voltage Detection (LVD): 2-Stage indicators, switchable (on or off)
• Thermal Protection: Thermal shutdown
• Profile selection:
• Sport Mode:
• 100% FWD, 100% brakes, 100% REV
• Race Mode:
• 100% FWD, 100% brakes, no REV
• Training Mode (patented):
• 50% FWD, 100% brakes, 50% REV
• Single-button setup: Yes, Traxxas EZ-Set®

* With 7-cell battery and included optional 31-tooth pinion gear
**Properly Geared
