Team Corally C-53020 CMM-8 Racing Controller 2S-4S ESC for Sensored & Sensorless Brushless Motors

Introducing the CMM-8 Racing Controller - 2-4S: Unleash the Power!

For top-level 1/8 racing, where speed and precision are everything, the CMM-8 Racing Controller - 2-4S is the key to unlocking your true potential on the track. Crafted with relentless attention to detail, this controller is designed to deliver unmatched performance when you need it most.

FEATURES:

• Pure Power, Uncompromising Performance - With up to 240A continuous current and a staggering 1100A burst current, the CMM-8 Racing Controller - 2-4S is built to provide the power and reliability required for elite-level racing. It's your path to victory, and it doesn't compromise.
• 32-Bit MCU for Precision Control - At its core, the CMM-8 features a high-performance 32-Bit Microcontroller Unit (MCU). This powerhouse provides superior processing capabilities, ensuring that your controller delivers accurate power output and lightning-fast response times.
• Optimized Software for Dominant Racing - The software design is honed to perfection, offering enhanced throttle response, exceptional acceleration, linearity, and driveability. With the CMM-8, every twist of the throttle translates into pure precision.
• Sensored and Sensorless Versatility - The CMM-8 Racing Controller - 2-4S seamlessly accommodates both sensored and sensorless motors, allowing you to choose the power source that suits your style and strategy.
• Revolutionary Remote Programming - Enjoy unparalleled convenience with direct remote programming through the custom Corally iOS and Android App. All the communication devices are seamlessly integrated, allowing you to fine-tune your controller settings effortlessly.
• Customize Your Racing Experience - Multiple programmable parameters put you in control, letting you adjust your racing settings to perfection. Adapt to track conditions, driving styles, and competition with ease.
• Real-Time Data at Your Fingertips - Stay ahead of the competition with real-time data logging. Monitor crucial parameters such as temperature, voltage, timing, motor RPM, and more. This invaluable data empowers you to make informed decisions and optimize your racing strategy.
• Reliability Built to Last - Crafted with A-Grade components, the CMM-8 Racing Controller - 2-4S achieves super low Internal Resistance (IR) and delivers maximum performance consistently, propelling you to the front of the pack.
• Built-In BEC for Ultimate Convenience - Experience convenience like never before with the super built-in BEC, offering up to 15A boost current and switchable voltage between 6.0V and 7.4V. Your power needs are met with ease.
• Safety is Paramount - Multiple safety protections are integrated, including high voltage protection, low voltage cut-off protection, throttle signal loss protection, over-heat protection, and locked rotor protection. Your controller is designed to keep you safe and your equipment in top shape.
• Compact and Efficient Design - The ultra-compact design of the CMM-8 ensures it won't hinder your racing experience. Its full aluminum case is not just for aesthetics—it's engineered for maximum heat dissipation, ensuring optimal performance.
• Ready for Any Challenge - Racing doesn't always happen under ideal conditions. That's why the CMM-8 features a waterproof polymer-potted PCB and switch. Rain or shine, this controller is built to endure and excel.
• The CMM-8 Racing Controller - 2-4S is your ultimate tool for domination on the track. Elevate your racing experience, gain the competitive edge, and make every race a victory with this exceptional racing controller. Step into the future of racing with Corally.

SPECIFICATIONS:

• ESC- Input Voltage Range (V): 2S - 4S Li-Po
• ESC - Current - Cont. (A): 240
• ESC - Current - Burst (A): 1100
• ESC - BEC - Voltage (V): Select. 6.0V - 7.4V
• ESC - BEC - Cont. (A): 8
• ESC - BEC - Peak (A): 12
• ESC - Protection: Waterproof
• ESC - Cooling Fan: Yes, 30mm
• ESC - Case Material: Full Aluminium
• ESC - Firmware Update: Supported
• ESC - Telemetrie Aux.: No
• ESC - Data Logging: Yes, Real Time Data - Max Values
• ESC - Real-Time Data
  • ESC Status
  • Current (A)
  • RPM (T/min)
  • Throttle Status
  • Voltage (V)
• ESC - Length (mm): 55
• ESC - Width (mm): 42
• ESC - Thickness (mm): 36
• ESC - Wires (AWG) - Battery: 10 AWG
• ESC - Wires (AWG) - Motor: 10 AWG
• ESC - Connector - Battery: None
• ESC - Weight (g): 155
• ESC - Application: 1/8 Racing
• ESC - Motor Type: Sensored & Sensorless Brushless Motors
• ESC - Motor Control: Forward - Brake
• ESC - Level: Competition - High-End
